U / Ribbon / Trough Blender

U / Ribbon / Trough Blender

Working Principle U-type ribbon mixing machine is ideal for unifrom mixing. This U-type mixer consist of "U" shaped tank and inside the tank two spiral blades moving opposite direction to one another which are mixing and homogenizing the material.
Manual tilting system for material discharge proceeds with moving spiral blades for better discharge, titlting system make it easy to clean the tank.

MACHINE SAMPLES

U / Ribbon / Trough Blender
U / Ribbon / Trough Blender
U / Ribbon / Trough Blender

Mixer Capacities

U-Mixer 20kg
U-Mixer 50kg
U-Mixer 100kg
U-Mixer 250kg
U-Mixer 500kg
U-Mixer 1000kg

Specification

Electric Motor :

5hp /1440rpm /50Hz ,3 Phase

Spiral Motion :

Rotary Type

Tilting System :

Manual

Drum Filling Capacity :

180 litters

Drum Mixing Capacity :

100 litters

Drum Dimennsions (mm):

L 1016 x W 610 x H 689

Material type:

304-L /drum 14G /cladding 22G

Dimensions(mm):

L 1900 x W 700 x H 1422

Machine Weight:

250 kgs

Description

Application:

Detergents, chemicals, food products, bakery items, liquid with powder, granules mixing etc.

Principle Features:

Manual/Automatic tilting system for material removal, stainless steel spiral blades, stable structural design, hopper SS cap, stainless steel 304-L body easy to clean & easy to use, maintenance free.
