Pulverizer / Grinder

Pulverizer / Grinder

Description:
Dry grinding/herbs grinding machine uses the relative motion between movable and fixed teeth disc, the raw material to be crushed undertake the comprehensive action such as impacted by teeth, friction, impact between raw material, and finally the raw material is crushed. Its features are simple and solid in structure, stable in operation, a high in crushed efficiency. The crushed raw material can be discharged through the grinding chamber. Moreover, different sizes of raw material to be crushed can be obtained by changing the screen with different mesh.
Principle Features:
  • It is characteristics of simple structure, easy operation, low noise, and high capacity
  • The machine is made from stainless steel; no dust will rise when working
  • The desired granule size can be obtained by installing screens with different apertures

MACHINE SAMPLES

Pulverizer / Grinder
Pulverizer / Grinder
Pulverizer / Grinder
Pulverizer / Grinder

Specification

Capacity :

100 kg/hr.

Function :

Crushing, Grinding, Pulverizing.

Aperture Size :

1-6mm

Spindle Speed :

2840 rpm

Size of input granules :

12 (mm)

Size of output granules :

20-400 (mesh)

Motor :

5hp, 380V, 3-phase

Contact Parts :

SS-304-L

Non-Contact Parts :

SS-201

Weight :

250 (kg)

Dimension :

L 620 x W 775 x H 1450 (mm)

Description

Application:

Dry grinding / herbs grinding machine in fully stainless steel body.

Description:

high yield-high power pulverizer is suitable for grains, white sugar, spices and other material etc., crushing ability very fine, grinding faster & more delicate.
