Blister Packing Machine

Blister Packing Machine

The Blister Pack Machine provides a packing method that protects products from the elements while sealing them tightly enough to create tamper-resistance, in effect protecting them from both human and environmental interference via a single automated process.

MACHINE BAGS

Blister Packing Machine
Blister Packing Machine

Specification

Punch frequency :

20-40(times/min)

Output :

2400 blisters/hour

Max formed area and depth:

80*100*26

Standard travel range :

20-100(adjustable)

Standard blister :

80*57 (adjustable)

Air pressure :

0.4-0.6 Mpa

Total power :

380v/220v 50Hz 1.8Kw

Main motor power :

0.55Kw

PVC hard pieces :

0.15-0.5*80mm

PTP aluminum foil :

0.02-0.035*80mm

Dialysis paper :

50-100g*80mm

Mould cooling :

tap water or recycle water

Overall dimension (L*W*H) :

1400*460*890mm

Weight :

350kg

Description

Application:

The Blister Pack Machine provides a packing method that protects products from the elements while sealing them tightly enough to create tamper-resistance, in effect protecting them from both human and environmental interference via a single automated process.



Principle Features:

  • Variable Frequency Speed Regulating, PLC Circuit Control Panel.
  • Adjustable Travel adopts manipulator grip equipped with inching device, which had accurate synchronization.
  • Travel-type feeder is suitable for feeding capsules and tablets.
  • Mould spout location is convenient for replacing mould.
  • Exquisite machine is suitable for small-scale production and laboratory.
  • Organic glass safety cover.
